DRYING AND HEATING CHAMBERS FED SERIES
INFORMATION
- - Temperature range: ambient temperature plus 10 °C to 300 °C
- - Up to 30% lower energy consumption compared to conventional units on the market
- - High temperature accuracy thanks to APT.line™ technology
- - Adjustable fan speed
- - Controller with LCD display and enhanced time functions
- - Electromechanical control of the exhaust air flap
- - 2 chrome-plated racks
- - Units up to 115 liters are stackable
- - Class 2 integrated independent adjustable temperature safety device (DIN 12880) with visual alarm
- - Ergonomic handle design
- - Ethernet interface
- - USB port for recording data
| Models | Housing dimensions not incl. fittings and connections W x H x D [mm] | Internal dimension W x H x D [mm] | Net weight [kg] | Interior volume [L] |
|---|---|---|---|---|
| FED 56 | 560 x 625 x 565 | 400 x 440 x 345 | 39 | 60 |
| FED 115 | 710 x 735 x 605 | 550 x 550 x 385 | 54 | 116 |
| FED 260 | 810 x 965 x 760 | 650 x 780 x 515 | 85 | 259 |
| FED 720 | 1165 x 1590 x 870 | 1000 x 1300 x 570 | 166 | 741 |
